Product Details

  • Pixel pitch: 1.25mm
  • Module size: 320mm × 160mm × 8mm
  • Module resolution: 256 × 128 dots
  • LED encapsulation: SMD1010
  • Pixel configuration: 1R1G1B
  • Pixel density: 640,000 dots/m²
  • Scan mode: 64S
  • Port type: HUB320
  • Equilibrium brightness: 400CD
  • Best viewing angle: 160°(W) / 160°(H)
  • Module consumption: 22W
  • Driving mode: Constant drive
  • Frame frequency: 60Hz
  • Refresh frequency: 3840Hz
  • Gray scale/color: 16.7M colors
  • Mean free error time: >5000 hours
  • Working temperature: -10℃ to 60℃
  • Working humidity: 10% to 70%
  • Lamp failure frequency: <0.0001


  • LED flexible screen is a kind of LED display screen with characteristics such as flexibility and foldability. It is completed by fixing LED lamps on a flexible substrate, and can be customized in different shapes and sizes as needed.

    Flexible display screen models: PH1.25, PH1.53, PH1.86, P1.875, PH2, PH2.5, PH3, PH3.076, PH4, PH5.

    LED flexible screen has many characteristics, such as ultra-high definition, high reliability, flexibility, durability, safety, low energy consumption, environmental protection, etc.

    1. Ultra-high definition: LED flexible screen adopts the latest technology. It can provide extremely high-definition images with bright colors, and can clearly display videos, pictures, texts and other contents, so as to obtain better visual effects.

    2. High reliability: LED flexible screen adopts advanced high-reliability technology, has higher reliability, can provide longer service life, and save more costs.

    3. Flexibility: LED flexible screen can be customized according to customer requirements, and can be designed in a variety of shapes and sizes according to the actual needs of customers, so that it can better adapt to various space environments.

    4. Durability: LED flexible screen can withstand greater impact, has higher pressure resistance, and can withstand complex environments, thus achieving better durability.

    If you have relevant needs, welcome to order.
